HD-LDR-II Thermal Conductivity Tester Laser Flash Method Thermal Conductivity Testing / Material Thermal Conductivit

Image Grand : HD-LDR-II Thermal Conductivity Tester Laser Flash Method Thermal Conductivity Testing / Material Thermal Conductivit

Détails sur le produit:

Place of Origin:	China
Nom de marque:	Haida
Certification:	CE,,ISO
Model Number:	60082-HD

Conditions de paiement et expédition:

Minimum Order Quantity:	1
Prix:	Négociable
Packaging Details:	each set protected with resin fiber and PP film, then put into Strong wooden case with operation man
Delivery Time:	20 days after order confirmed
Payment Terms:	L/C, T/T, D/A, D/P, Western Union, MoneyGram
Supply Ability:	300 Sets per Month

Contact

HD-LDR-II Thermal Conductivity Tester Laser Flash Method Thermal Conductivity Testing / Material Thermal Conductivit

description de

Test range:	0.005—300W/(m*K)	Test mode A:	Room temperature
Test mode B:	RT~120℃ (Required other temp. Control device)	Probe diameter A:	7.5 mm
Probe diameter B:	15 mm	Resolution:	±3%
Repeatability error:	≤3%	Test time:	5~160 sec
Power:	AC 220V	External dimension(WHD):	504120 cm
Roller Wheel Length:	460mm	Injection Time:	0-9999s [Adjustable]
Material:	Rubber and Plastic	Dispaly:	Digital
Test Fixture:	5 sets	Transformer Capacity:	1000VA
Usage:	Testing the physical and mechanical properties of rubber and plastic materials	Swing Range:	R300mm
Control Temperature:	Within 70±1℃or 100±1℃to room temperature	Ozone Produced Mode:	Ozone generator or UV absorption method
Thermal Range:	RT~1000℃	Load Cell Capacity:	500N
Lamp Size:	Ф31*(450±50)mm	Controlling Accuracy:	±0.2°C
Mettre en évidence:	Thermal Conductivity Tester Laser Flash Method , Thermal Conductivity Tester

HD-LDR-II Thermal Conductivity Tester

(Laser Flash Method)

Description:

This instrument is suitable for measuring the thermal diffusivity and thermal conductivity of high thermal conductivity solid materials, such as metals, graphite, etc., in accordance with the national standard GB/T 22588-2008 "Flash Method for Measuring Thermal Diffusivity or Thermal Conductivity" and ASTM E 1461--2001 "Flash Method for Determining Thermal Diffusivity Test Method".

HD-LDR-II Thermal Conductivity Tester Laser Flash Method Thermal Conductivity Testing / Material Thermal Conductivit 0

Technical Parameters

Item	Parameters
Thermal conductivity measurement range	0.1~2000w/m.k, resolution: 0.1w/m.k
Sample size	Φ12×(0.1~5)mm, square=10x10mm, thickness 1~3mm
Laser source power	200W adjustable
Test accuracy	±3%
Repeatability	Deviation between two measurements <±3%
Testing results	The computer can simultaneously calculate multiple thermal parameters such as thermal diffusion coefficient (thermal conductivity), specific heat capacity, etc.
Control mode	Can communicate with general computers, use fully automatic test software, quickly and accurately analyze the test process parameters and output reports for samples
Power	1∮ AC 220V 50HZ 500W

About us

Haida International Equipment Co,Ltd was established in 2004, located in Dongguan city, Guangdong Province, China, is specialized in production and R&D of various material physical properties testing equipment. We have our own independent research and development center and four testing equipment production lines: textile, footwear, leather, mask. In 2006, textile, footwear, leather mask testing equipment officially put into production and entered the international market.

Why choose us?

1.Design & Production : Solution Consultation for each order
Recommend the most cost -performance machine
Research & Develop the suitable one for Special- designed Model.
2.Shipping & Delivery: One-Stop Service
Production- Deliver to your door - Installation & Training- Technical Support
3.Warranty
1 year warranty with lifetime technology support
4.After-Sale Service
React within 2 Hours
Video inspection & on-site service combined

FAQ

Q: How about your warranty?

A: Generally, our warranty is one year. Within the warranty period, we can offer technique support and part parts change, if it's necessary, our engineers may go to your place for better service.

Q: What is the order process?

A: Get Inquiry - Send the Quotation - Confirm the requirements - Order confirming - Payment - production - testing and debugging- packing - Confirm with customer about the necessary documents- Arrangement the Delivery - Send the product out - Customer Receiving - After Service.

Q: Can we visit your factory before order?

A: Yes, we warmly welcome and sincerely invite you and your team to visit our factory, we will help to arrange hotel and pick up you from airport.

Q: Do you accept customization service?

A: Yes, of course, we can not only offer standard machines, but also customized machines according to your request. Don't hesitate to tell us your requirement, we will do our best to meet your needs.
